دیتاشیت TPS72011DRVT
مشخصات دیتاشیت
| نام دیتاشیت | TPS720xx Datasheet |
|---|---|
| حجم فایل | 1043.399 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 28 |
دانلود دیتاشیت TPS720xx Datasheet |
TPS720xx Datasheet Datasheet |
|---|
مشخصات
- Current - Supply (Max): 80µA
- Output Configuration: Positive
- Package / Case: 6-WDFN Exposed Pad
- Packaging: Cut Tape (CT)
- Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
- Number of Regulators: 1
- Part Status: Active
- Current - Quiescent (Iq): 38µA
- Operating Temperature: -40°C ~ 125°C (TJ)
- Supplier Device Package: 6-WSON (2x2)
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 4.5V
- Voltage - Output (Min/Fixed): 1.1V
- Mounting Type: Surface Mount
- PSRR: 85dB ~ 50dB (10Hz ~ 1MHz)
- Base Part Number: TPS720
- Series: -
- Output Type: Fixed
- Control Features: Enable
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.2V @ 350mA
- Current - Output: 350mA
- detail: Linear Voltage Regulator IC 1 Output 350mA 6-WSON (2x2)
