دیتاشیت TN3015H-6G
مشخصات دیتاشیت
نام دیتاشیت |
TN3015H-6G
|
حجم فایل |
267.659
کیلوبایت
|
نوع فایل |
pdf
|
تعداد صفحات |
11
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
ECOPACK®2
-
Packaging:
Tube
-
Part Status:
Active
-
Voltage - Off State:
600mV
-
Voltage - Gate Trigger (Vgt) (Max):
1.3V
-
Current - Gate Trigger (Igt) (Max):
15mA
-
Voltage - On State (Vtm) (Max):
1.6V
-
Current - On State (It (AV)) (Max):
19A
-
Current - On State (It (RMS)) (Max):
30A
-
Current - Hold (Ih) (Max):
60mA
-
Current - Off State (Max):
10µA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
270A, 295A
-
SCR Type:
Standard Recovery
-
Operating Temperature:
-40°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
-
Supplier Device Package:
D2PAK
-
detail:
SCR 600mV 30A Standard Recovery Surface Mount D2PAK
