SN74LVC245AIPWREP دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC245AIPWREP |
|---|---|
| حجم فایل | 102.635 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت SN74LVC245AIPWREP |
دانلود دیتاشیت |
|---|
سایر مستندات
Logic Guide 20 pages
SN74LVC245A-EP 11 pages
مشخصات فنی
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74LVC245AIPWREP
- Input type: -
- output type: Tri-State
- Logic Family: 74LVC
- Sink Current: 24mA
- Source Current: 24mA
- Supply Voltage: 1.65V~3.6V
- Number of Elements: 1
- Operating Temperature: -40°C~+85°C
- Number of Bits per Element: 8
- Package: TSSOP-20
- Manufacturer: Texas Instruments
- Voltage - Supply: 1.65V ~ 3.6V
- Mounting Type: Surface Mount
- Packaging: Cut Tape (CT)
- Package / Case: 20-TSSOP (0.173", 4.40mm Width)
- Part Status: Active
- Current - Output High, Low: 24mA, 24mA
- Series: 74LVC
- Supplier Device Package: 20-TSSOP
- Logic Type: Transceiver, Non-Inverting
- Base Part Number: SN74LVC24
- detail: Transceiver, Non-Inverting 1 Element 8 Bit per Element 3-State Output 20-TSSOP
