STTH16L06C دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STTH16L06C
|
|
حجم فایل
|
135.637
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Diodes - General Purpose
-
Datasheet:
STMicroelectronics STTH16L06CFP
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
200V
-
Forward Voltage (Vf@If):
2.08V@16A
-
Reverse Leakage Current:
8uA@200V
-
Average Rectified Current (Io):
10A
-
Package:
TO-220F
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
600V
-
Current - Average Rectified (Io) (per Diode):
8A
-
Voltage - Forward (Vf) (Max) @ If:
1.8V @ 8A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Reverse Recovery Time (trr):
55ns
-
Current - Reverse Leakage @ Vr:
8µA @ 600V
-
Operating Temperature - Junction:
175°C (Max)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3 Full Pack
-
Supplier Device Package:
TO-220FP
-
Base Part Number:
STTH16
-
detail:
Diode Array 1 Pair Common Cathode Standard 600V 8A Through Hole TO-220-3 Full Pack
