STPS20L60CT دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | STPS20L60CT |
|---|---|
| حجم فایل | 45.84 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 11 |
دانلود دیتاشیت STPS20L60CT |
دانلود دیتاشیت |
|---|
سایر مستندات
STPS20L60CT/CG/CR 10 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: STMicroelectronics STPS20L60CT
- Diode Configuration: Dual Common Cathode
- Reverse Voltage (Vr): 60V
- Forward Voltage (Vf@If): 600mV@10A
- Reverse Leakage Current (Ir): 350uA@60V
- Average Rectified Current (Io): 10A
- Package: TO-220AB-3
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tube
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 60V
- Current - Average Rectified (Io) (per Diode): 10A
- Voltage - Forward (Vf) (Max) @ If: 600mV @ 10A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 350µA @ 60V
- Operating Temperature - Junction: 150°C (Max)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB
- Base Part Number: STPS20
- detail: Diode Array 1 Pair Common Cathode Schottky 60V 10A Through Hole TO-220-3
