- دیتاشیت CSD17581Q5AT
CSD17581Q5AT دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | CSD17581Q5AT |
|---|---|
| حجم فایل | 83.568 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت CSD17581Q5AT |
دانلود دیتاشیت |
|---|
سایر مستندات
CSD17581Q5A Datasheet 13 pages
مشخصات فنی
- RoHS: true
- Category: Triode/MOS Tube/Transistor/MOSFETs
- Datasheet: Texas Instruments CSD17581Q5AT
- Package: DFN-8(4.9x5.8)
- Manufacturer: Texas Instruments
- Power Dissipation (Max): 3.1W (Ta), 83W (Tc)
- Drain to Source Voltage (Vdss): 30V
- Rds On (Max) @ Id, Vgs: 3.4mOhm @ 16A, 10V
- Vgs (Max): ±20V
- FET Type: N-Channel
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Technology: MOSFET (Metal Oxide)
- Current - Continuous Drain (Id) @ 25°C: 24A (Ta), 123A (Tc)
- FET Feature: -
- Input Capacitance (Ciss) (Max) @ Vds: 3640pF @ 15V
- Operating Temperature: -55°C ~ 150°C (TJ)
- Packaging: Cut Tape (CT)
- Package / Case: 8-PowerTDFN
- Part Status: Active
- Series: NexFET™
- Vgs(th) (Max) @ Id: 1.7V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 54nC @ 10V
- Supplier Device Package: 8-VSONP (5x6)
- Mounting Type: Surface Mount
- Base Part Number: CSD175
- detail: N-Channel 30V 24A (Ta), 123A (Tc) 3.1W (Ta), 83W (Tc) Surface Mount 8-VSONP (5x6)
