دیتاشیت LM27402SQ/NOPB
مشخصات دیتاشیت
| نام دیتاشیت |
LM27402
|
| حجم فایل |
3018.75
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
52
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Controllers
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Texas Instruments LM27402SQ/NOPB
-
Input Voltage:
3V~20V
-
Number of Outputs:
1
-
Switching Frequency:
1.2MHz
-
Synchronous Rectification:
Yes
-
Package:
QFN-16-EP(4x4)
-
Manufacturer:
Texas Instruments
-
Part Status:
Active
-
Package / Case:
16-WQFN Exposed Pad
-
Packaging:
Cut Tape (CT)
-
Frequency - Switching:
200kHz ~ 1.2MHz
-
Supplier Device Package:
16-WQFN (4x4)
-
Serial Interfaces:
-
-
Synchronous Rectifier:
Yes
-
Clock Sync:
Yes
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Output Configuration:
Positive
-
Base Part Number:
LM27402
-
Series:
-
-
Output Type:
Transistor Driver
-
Control Features:
Current Limit, Enable, Frequency Control, Power Good, Soft Start, Tracking
-
Output Phases:
1
-
Duty Cycle (Max):
95%
-
Voltage - Supply (Vcc/Vdd):
3V ~ 20V
-
detail:
Buck Regulator Positive Output Step-Down DC-DC Controller IC 16-WQFN (4x4)
