TPS62091RGTT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS62091RGTT
|
|
حجم فایل
|
82.354
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
27
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Texas Instruments TPS62091RGTT
-
Output Type:
Fixed
-
Input Voltage:
2.5V~6V
-
Output Voltage:
3.3V
-
Number of Outputs:
1
-
Switching Frequency:
2.8MHz
-
Output Current (Max):
3A
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
Yes
-
Package:
QFN-16-EP(3x3)
-
Manufacturer:
Texas Instruments
-
Current - Output:
3A
-
Voltage - Input (Max):
6V
-
Frequency - Switching:
2.8MHz
-
Part Status:
Active
-
Base Part Number:
TPS620
-
Voltage - Output (Min/Fixed):
3.3V
-
Package / Case:
16-VFQFN Exposed Pad
-
Series:
DCS-Control™
-
Packaging:
Cut Tape (CT)
-
Synchronous Rectifier:
Yes
-
Output Configuration:
Positive
-
Voltage - Output (Max):
-
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
16-QFN (3x3)
-
Voltage - Input (Min):
2.5V
-
detail:
Buck Switching Regulator IC Positive Fixed 3.3V 1 Output 3A 16-VFQFN Exposed Pad
