دیتاشیت UC2843N
مشخصات دیتاشیت
| نام دیتاشیت | UC2843N |
|---|---|
| حجم فایل | 82.219 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 11 |
UC2843N |
دانلود دیتاشیت |
|---|
سایر مستندات
UC1842-45, UC2842-45, UC3842-45 55 pages
UC2842D 55 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/AC-DC Controllers & Regulators
- Datasheet: HGSEMI UC2843N
- Package: DIP-8
- Manufacturer: HGSEMI
- Topology: Boost;Step-down;Step-down-Boost;Flyback;Forward
- Duty Cycle: 97%
- Supply Voltage: 12V~28V
- Switching Frequency: 500kHz
- Operating Temperature: -40°C~+85°C@(Ta)
- Part Status: Active
- Package / Case: 8-DIP (0.300", 7.62mm)
- Packaging: Tube
- Frequency - Switching: Up to 500kHz
- Supplier Device Package: 8-PDIP
- Number of Outputs: 1
- Serial Interfaces: -
- Synchronous Rectifier: No
- Function: Step-Up, Step-Down, Step-Up/Step-Down
- Clock Sync: No
- Mounting Type: Through Hole
- Output Configuration: Positive
- Base Part Number: UC284
- Series: -
- Output Type: Transistor Driver
- Control Features: Frequency Control
- Output Phases: 1
- Duty Cycle (Max): 97%
- Voltage - Supply (Vcc/Vdd): 12V ~ 28V
- detail: Boost, Buck, Buck-Boost, Flyback, Forward Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 8-PDIP
