دیتاشیت LM2931Z-5.0/NOPB
مشخصات دیتاشیت
| نام دیتاشیت |
LM2931 Series
|
| حجم فایل |
3658.714
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
33
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments LM2931Z-5.0/NOPB
-
Output Current:
100mA
-
Output Voltage:
5V
-
Dropout Voltage:
0.3V@(100mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
26V
-
Operating Temperature:
-40°C~+85°C
-
Quiescent Current (Ground Current):
1mA
-
Power Supply Rejection Ratio (PSRR):
55dB@(120Hz)
-
Package:
TO-92-3
-
Manufacturer:
Texas Instruments
-
Current - Supply (Max):
15mA
-
Output Configuration:
Positive
-
Package / Case:
TO-226-3, TO-92-3 (TO-226AA)
-
Packaging:
Bulk
-
Protection Features:
Over Temperature, Reverse Polarity, Short Circuit
-
Number of Regulators:
1
-
Part Status:
Active
-
Current - Quiescent (Iq):
1mA
-
Supplier Device Package:
TO-92-3
-
Voltage - Input (Max):
26V
-
Voltage - Output (Min/Fixed):
5V
-
Mounting Type:
Through Hole
-
PSRR:
55dB (120Hz)
-
Base Part Number:
LM2931
-
Series:
-
-
Output Type:
Fixed
-
Control Features:
-
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.3V @ 100mA
-
Current - Output:
100mA
-
detail:
Linear Voltage Regulator IC 1 Output 100mA TO-92-3
