CSD87351Q5D دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت CSD87351Q5D	دانلود دیتاشیت

RoHS: true
Type: 2 N-Channel
Category: Triode/MOS Tube/Transistor/MOSFETs
Datasheet: Texas Instruments CSD87351Q5D
Operating Temperature: -55°C~+150°C@(Tj)
Power Dissipation (Pd): 12W
Total Gate Charge (Qg@Vgs): 7.7nC@4.5V
Drain Source Voltage (Vdss): 30V
Input Capacitance (Ciss@Vds): 1255pF@15V
Continuous Drain Current (Id): 32A
Gate Threshold Voltage (Vgs(th)@Id): 2.1V@250uA
Drain Source On Resistance (RDS(on)@Vgs,Id): 7.6mΩ@8V,20A
Package: LSON-8(5x6)
Manufacturer: Texas Instruments
Drain to Source Voltage (Vdss): 30V
Power - Max: 12W
Rds On (Max) @ Id, Vgs: 7.6mOhm @ 20A, 8V
FET Type: 2 N-Channel (Dual)
Part Status: Active
Current - Continuous Drain (Id) @ 25°C: 32A
FET Feature: Logic Level Gate
Input Capacitance (Ciss) (Max) @ Vds: 1255pF @ 15V
Packaging: Cut Tape (CT)
Package / Case: 8-PowerLDFN
Series: NexFET™
Vgs(th) (Max) @ Id: 2.1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 7.7nC @ 4.5V
Supplier Device Package: 8-LSON (5x6)
Mounting Type: Surface Mount
Base Part Number: CSD87351
detail: Mosfet Array 2 N-Channel (Dual) 30V 32A 12W Surface Mount 8-LSON (5x6)
