TL431 Datasheet دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TL431 Datasheet
|
|
حجم فایل
|
861.678
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
21
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Voltage References
-
Datasheet:
STMicroelectronics TL431IL3T
-
Tolerance:
±2.21%
-
Output Type:
Adjustable
-
Input Voltage:
-
-
Output Current:
100mA
-
Output Voltage:
2.495V~36V
-
Reference Type:
parallel connection
-
Supply Current:
-
-
Noise - 10Hz to 10kHz:
-
-
Operating Temperature:
-40°C~+105°C@(Ta)
-
Noise - 1/10Hz to 10Hz:
-
-
Temperature Coefficient:
-
-
Minimum Cathode Current for Regulation:
1mA
-
Package:
SOT-23
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Output (Min/Fixed):
2.495V
-
Voltage - Output (Max):
36V
-
Current - Output:
100mA
-
Noise - 0.1Hz to 10Hz:
-
-
Voltage - Input:
-
-
Current - Supply:
-
-
Current - Cathode:
1mA
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3
-
Base Part Number:
TL431
-
detail:
Shunt Voltage Reference IC 36V ±2.21% SOT-23-3
