TPS54418A Datasheet دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TPS54418A Datasheet	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Texas Instruments TPS54418ARTET
Output Type: Adjustable
Input Voltage: 2.95V~6V
Output Voltage: 0.8V~4.5V
Number of Outputs: 1
Switching Frequency: 2MHz
Output Current (Max): 4A
Operating Temperature: -40°C~+150°C@(TJ)
Synchronous Rectification: Yes
Package: QFN-16-EP(3x3)
Manufacturer: Texas Instruments
Current - Output: 4A
Voltage - Input (Max): 6V
Frequency - Switching: 200kHz ~ 2MHz
Part Status: Active
Base Part Number: TPS544
Voltage - Output (Min/Fixed): 0.8V
Package / Case: 16-WFQFN Exposed Pad
Series: SWIFT™
Packaging: Cut Tape (CT)
Synchronous Rectifier: Yes
Output Configuration: Positive
Voltage - Output (Max): 4.5V
Mounting Type: Surface Mount
Supplier Device Package: 16-WQFN (3x3)
Voltage - Input (Min): 2.95V
detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 4A 16-WFQFN Exposed Pad
