L78M12ACDT-TR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | L78M12ACDT-TR |
|---|---|
| حجم فایل | 666.438 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 31 |
دانلود دیتاشیت L78M12ACDT-TR |
دانلود دیتاشیت |
|---|
سایر مستندات
L78MxxAB,AC 29 pages
L78M05ACDT-TR 29 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: STMicroelectronics L78M12ACDT-TR
- Output Type: Fixed
- Output Current: 500mA
- Output Voltage: 12V
- Dropout Voltage: -
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 35V
- Operating Temperature: 0°C~+125°C
- Quiescent Current (Ground Current): 6mA
- Power Supply Rejection Ratio (PSRR): 55dB@(120Hz)
- Package: TO-252
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 35V
- Voltage - Output (Min/Fixed): 12V
- Voltage - Output (Max): -
- Voltage Dropout (Max): -
- Current - Output: 500mA
- Current - Quiescent (Iq): 6mA
- PSRR: 55dB (120Hz)
- Control Features: -
- Protection Features: Over Current, Over Temperature, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: DPAK
- Base Part Number: L78M12
- detail: Linear Voltage Regulator IC 1 Output 500mA DPAK
