دیتاشیت STPS40150CW

مشخصات دیتاشیت

دانلود دیتاشیت STPS40150Cx	STPS40150Cx Datasheet

RoHS: true
Category: Diodes/Schottky Barrier Diodes (SBD)
Datasheet: STMicroelectronics STPS40150CW
Diode Configuration: Dual Common Cathode
Reverse Voltage (Vr): 150V
Forward Voltage (Vf@If): 1V@40A
Reverse Leakage Current (Ir): 2uA@150V
Average Rectified Current (Io): 20A
Package: TO-247
Manufacturer: STMicroelectronics
Series: -
Packaging: Tube
Part Status: Active
Diode Type: Schottky
Voltage - DC Reverse (Vr) (Max): 150V
Current - Average Rectified (Io) (per Diode): 20A
Voltage - Forward (Vf) (Max) @ If: 920mV @ 20A
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr: 8µA @ 150V
Operating Temperature - Junction: 175°C (Max)
Mounting Type: Through Hole
Package / Case: TO-247-3
Supplier Device Package: TO-247-3
Base Part Number: STPS401
detail: Diode Array 1 Pair Common Cathode Schottky 150V 20A Through Hole TO-247-3
