TN1605H-6FP 数据手册
其他文档
TN1605H-6FP 9 pages
技术规格
- RoHS: true
- Category: Triode/MOS Tube/Transistor/TRIACs
- SCR Type: One-way thyristor
- Datasheet: STMicroelectronics TN1605H-6FP
- Holding Current (Ih): 20mA
- Operating Temperature: -40°C~+150°C
- Gate Trigger Current(Igt): 6mA
- Gate Trigger Voltage (Vgt): 1.3V
- RMS On-State Current(It (rms)): 16A
- Peak Forward On?State Voltage (Vtm): 1.6V
- Peak Repetitive Off?State Voltage (Vdrm): 600V
- Package: TO-220
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tube
- Part Status: Active
- Voltage - Off State: 600V
- Voltage - Gate Trigger (Vgt) (Max): 1.3V
- Current - Gate Trigger (Igt) (Max): 6mA
- Voltage - On State (Vtm) (Max): 1.6V
- Current - On State (It (AV)) (Max): 10A
- Current - On State (It (RMS)) (Max): 16A
- Current - Hold (Ih) (Max): 20mA
- Current - Off State (Max): 5µA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 140A, 153A
- Mounting Type: Through Hole
- Package / Case: TO-220-3 Full Pack
- Supplier Device Package: TO-220FP
- Base Part Number: TN1605
- detail: SCR 600V 16A Standard Recovery Through Hole TO-220FP
