دیتاشیت BZW04-5V8B

BZW04-5V8(B) thru 376(B) Datasheet

مشخصات دیتاشیت

نام دیتاشیت BZW04-5V8(B) thru 376(B) Datasheet
حجم فایل 121.674 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت BZW04-5V8(B) thru 376(B) Datasheet

BZW04-5V8(B) thru 376(B) Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: STMicroelectronics BZW04-5V8B
  • Breakdown Voltage: 6.45V
  • Bidirectional Channels: 1
  • Maximum Clamping Voltage: 10.5V
  • Reverse Leakage Current (Ir): -
  • Reverse Stand-Off Voltage (Vrwm): 5.8V
  • Peak Pulse Current (Ipp)@10/1000us: 38A
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 400W
  • Package: DO-15
  • Manufacturer: STMicroelectronics
  • Series: BZW04, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 5.8V
  • Voltage - Breakdown (Min): 6.45V
  • Voltage - Clamping (Max) @ Ipp: 10.5V
  • Current - Peak Pulse (10/1000µs): 38A
  • Power - Peak Pulse: 400W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 1750pF @ 1MHz
  • Operating Temperature: -
  • Mounting Type: Through Hole
  • Package / Case: DO-204AC, DO-15, Axial
  • Supplier Device Package: DO-15
  • Base Part Number: BZW04
  • detail: 10.5V Clamp 38A Ipp Tvs Diode Through Hole DO-15
