TS5N412 23 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TS5N412PW
Turn-on time: 200ns
Turn-off time: 200ns
Supply Voltage: 4.75V~5.25V
Switch Circuit: SPDT(SPDT)
Number of Channels: 4
On-State Resistance (Max): 12.5Ω
Package: TSSOP-16
Manufacturer: Texas Instruments
Current - Leakage (IS(off)) (Max): -
Voltage - Supply, Single (V+): 4.75V ~ 5.25V
Voltage - Supply, Dual (V±): -
Number of Circuits: 4
Channel-to-Channel Matching (ΔRon): -
Package / Case: 16-TSSOP (0.173", 4.40mm Width)
Part Status: Active
Supplier Device Package: 16-TSSOP
Switch Time (Ton, Toff) (Max): 200ns, 200ns
Packaging: Tube
-3db Bandwidth: 25MHz (Min)
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Crosstalk: -50dB @ 25MHz
Base Part Number: TS5N41
Series: -
Channel Capacitance (CS(off), CD(off)): -
Multiplexer/Demultiplexer Circuit: 2:1
Charge Injection: -
detail: 4 Circuit IC Switch 2:1 12.5Ohm 16-TSSOP
