دیتاشیت LM2591HVSX-3.3/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM2591HV |
|---|---|
| حجم فایل | 3431.118 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 31 |
دانلود دیتاشیت LM2591HV |
LM2591HV Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments LM2591HVSX-3.3/NOPB
- Output Type: Fixed
- Input Voltage: 4.5V~60V
- Output Voltage: 3.3V
- Number of Outputs: 1
- Switching Frequency: 150kHz
- Output Current (Max): 1A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: TO-263-5
- Manufacturer: Texas Instruments
- Package / Case: TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
- Output Configuration: Positive
- Base Part Number: LM2591
- Packaging: Cut Tape (CT)
- Frequency - Switching: 150kHz
- Supplier Device Package: DDPAK/TO-263-5
- Part Status: Obsolete
- Current - Output: 1A
- Series: SIMPLE SWITCHER®
- Voltage - Input (Max): 60V
- Synchronous Rectifier: No
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Input (Min): 4.5V
- Mounting Type: Surface Mount
- Voltage - Output (Max): -
- detail: Buck Switching Regulator IC Positive Fixed 3.3V 1 Output 1A TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
