TPS75918KTTT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS75918KTTT
|
|
حجم فایل
|
97.997
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
29
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS75918KTTT
-
Output Current:
7.5A
-
Output Voltage:
1.8V
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
200uA
-
Power Supply Rejection Ratio (PSRR):
58dB@(100Hz)
-
Package:
TO-263-5
-
Manufacturer:
Texas Instruments
-
Voltage - Input (Max):
5.5V
-
Current - Quiescent (Iq):
200µA
-
Output Configuration:
Positive
-
Base Part Number:
TPS759
-
Voltage - Output (Min/Fixed):
1.8V
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
PSRR:
58dB (100Hz)
-
Supplier Device Package:
DDPAK/TO-263-5
-
Package / Case:
TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
-
Number of Regulators:
1
-
Part Status:
Active
-
Output Type:
Fixed
-
Control Features:
Enable, Power Good
-
Voltage - Output (Max):
-
-
Mounting Type:
Surface Mount
-
Voltage Dropout (Max):
-
-
Current - Output:
7.5A
-
detail:
Linear Voltage Regulator IC 1 Output 7.5A DDPAK/TO-263-5
