دیتاشیت TLC1543CDB
مشخصات دیتاشیت
| نام دیتاشیت | TLC1542I/M/Q/C, TLC1543C/I/Q |
|---|---|
| حجم فایل | 1738.701 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 37 |
دانلود دیتاشیت TLC1542I/M/Q/C, TLC1543C/I/Q |
TLC1542I/M/Q/C, TLC1543C/I/Q Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments TLC1543CDB
- Interface: SPI
- resolution: 10Bit
- Supply Voltage: 5V
- number of channels: 11
- sampling frequency: 38kHz
- Operating Temperature: 0°C~+70°C
- Package: SSOP-20
- Manufacturer: Texas Instruments
- Architecture: SAR
- Input Type: Single Ended
- Series: -
- Ratio - S/H:ADC: 1:1
- Packaging: Tube
- Data Interface: SPI
- Reference Type: External
- Part Status: Active
- Supplier Device Package: 20-SSOP
- Number of A/D Converters: 1
- Sampling Rate (Per Second): 38k
- Configuration: MUX-S/H-ADC
- Package / Case: 20-SSOP (0.209", 5.30mm Width)
- Mounting Type: Surface Mount
- Base Part Number: TLC154
- Features: Selectable Address
- Number of Bits: 10
- Number of Inputs: 11
- Voltage - Supply, Analog: 5V
- Voltage - Supply, Digital: 5V
- detail: 10 Bit Analog to Digital Converter 11 Input 1 SAR 20-SSOP
