- UCC2813QDR-3Q1
UCC2813QDR-3Q1 Datasheet
Datasheet specifications
| Datasheet's name | UCC2813QDR-3Q1 |
|---|---|
| File size | 106.555 KB |
| File type | |
| Number of pages | 46 |
Download Datasheet UCC2813QDR-3Q1 |
Download Datasheet |
|---|
Other documentations
Power Management Guide 93 pages
UCC2813-x-Q1 46 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/AC-DC Controllers & Regulators
- Topology: Boost;Flyback;Forward
- Datasheet: Texas Instruments UCC2813QDR-3Q1
- Supply Voltage: 3.6V~12V
- Package: SOP-8
- Manufacturer: Texas Instruments
- Part Status: Active
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Packaging: Cut Tape (CT)
- Frequency - Switching: -
- Supplier Device Package: 8-SOIC
- Number of Outputs: 1
- Serial Interfaces: -
- Synchronous Rectifier: No
- Function: Step-Up, Step-Up/Step-Down
- Clock Sync: No
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Output Configuration: Positive
- Base Part Number: UCC281
- Series: Automotive, AEC-Q100
- Output Type: Transistor Driver
- Control Features: Frequency Control
- Output Phases: 1
- Duty Cycle (Max): 99%
- Voltage - Supply (Vcc/Vdd): 3.6V ~ 12V
- detail: Boost, Flyback, Forward Converter Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
