LM140L, LM340L Series Datasheet

LM140L, LM340L Series

Datasheet specifications

Datasheet's name LM140L, LM340L Series
File size 564.227 KB
File type pdf
Number of pages 16

Download Datasheet LM140L, LM340L Series

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Output Current: 100mA
  • Output Voltage: 5V
  • Dropout Voltage: 2V@(1A)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 35V
  • Operating Temperature: -55°C~+125°C
  • Quiescent Current (Ground Current): 3mA
  • Power Supply Rejection Ratio (PSRR): 72dB@(120Hz)
  • Package: TO-39
  • Manufacturer: Texas Instruments
  • Current - Supply (Max): 4.5mA
  • Output Configuration: Positive
  • Package / Case: TO-205AD, TO-39-3 Metal Can
  • Packaging: Bulk
  • Protection Features: Over Temperature, Short Circuit
  • Number of Regulators: 1
  • Part Status: Active
  • Current - Quiescent (Iq): 3mA
  • Supplier Device Package: TO-39-3
  • Voltage - Input (Max): 35V
  • Voltage - Output (Min/Fixed): 5V
  • Mounting Type: Through Hole
  • PSRR: 72dB (120Hz)
  • Base Part Number: LM140
  • Series: -
  • Output Type: Fixed
  • Control Features: -
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 2V @ 1A
  • Current - Output: 100mA
  • detail: Linear Voltage Regulator IC 1 Output 100mA TO-39-3
