MSP430FR4xx, MSP430FR2xx Family User Guide 数据手册
数据手册规格
| 数据手册名称 | MSP430FR4xx, MSP430FR2xx Family User Guide |
|---|---|
| 文件大小 | 4015.801 千字节 |
| 文件类型 | |
| 页数 | 676 |
下载数据手册 MSP430FR4xx, MSP430FR2xx Family User Guide |
下载数据手册 |
|---|
其他文档
MSP430FR263x,253x Datasheet 108 pages
MSP430FR263x, MSP430FR253x Getting Started Guide 4 pages
MSP430FR4xx, MSP430FR2xx Bootloader User Guide 2 pages
MSP430FR2532IRGET 109 pages
MSP430FR2533 Errata 15 pages
技术规格
- RoHS: true
- EEPROM: -
- CPU Core: MSP430
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: -
- ADC (Bit): 10bit
- DAC (Bit): -
- Datasheet: Texas Instruments MSP430FR2533IDA
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 16MHz
- GPIO Ports Number: 19
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 15.5KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: TSSOP-32-6.1mm
- Manufacturer: Texas Instruments
- Speed: 16MHz
- Data Converters: A/D 8x10b
- Oscillator Type: Internal
- Package / Case: 32-TSSOP (0.240", 6.10mm Width)
- Packaging: Bulk
- Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
- Part Status: Active
- Supplier Device Package: 32-TSSOP
- Core Size: 16-Bit
- Core Processor: MSP430
- Program Memory Size: 15.5KB (15.5K x 8)
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Number of I/O: 19
- Base Part Number: 430FR2533
- Series: MSP430™ FRAM
- EEPROM Size: -
- Connectivity: I²C, IrDA, SCI, SPI, UART/USART
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- detail: MSP430 MSP430™ FRAM Microcontroller IC 16-Bit 16MHz 15.5KB (15.5K x 8) FRAM 32-TSSOP
