TLC193, TLC393 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TLC193, TLC393
|
|
حجم فایل
|
1587.432
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
33
|
مشخصات فنی
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Comparators
-
Datasheet:
Texas Instruments TLC393QDR
-
Output Type:
MOS;Open Drain
-
Supply Voltage:
4V~16V
-
Number of Elements:
-
-
Operating Temperature:
-40°C~+125°C
-
Input Bias Current (Ib):
5pA
-
Input Offset Voltage (Vos):
5mV
-
Input Hysteresis Voltage (Vhys):
-
-
Common Mode Rejection Ratio (CMRR):
84dB
-
Package:
SOP-8
-
Manufacturer:
Texas Instruments
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Propagation Delay (Max):
4.5µs
-
Current - Quiescent (Max):
90µA
-
Voltage - Input Offset (Max):
5mV @ 10V
-
Part Status:
Active
-
Current - Output (Typ):
20mA
-
Current - Input Bias (Max):
5pA @ 5V
-
Packaging:
Cut Tape (CT)
-
Type:
General Purpose
-
CMRR, PSRR (Typ):
84dB CMRR
-
Voltage - Supply, Single/Dual (±):
4V ~ 16V
-
Series:
LinCMOS™
-
Base Part Number:
TLC393
-
Supplier Device Package:
8-SOIC
-
Mounting Type:
Surface Mount
-
Hysteresis:
-
-
detail:
Comparator General Purpose MOS, Open-Drain 8-SOIC
