LF156H Datasheet
Datasheet specifications
| Datasheet's name | LF156H |
|---|---|
| File size | 100.765 KB |
| File type | |
| Number of pages | 46 |
Download Datasheet LF156H |
Download Datasheet |
|---|
Other documentations
LF155-56, LF256-57, LF355-57 45 pages
Technical specifications
- RoHS: true
- Category: Operational Amplifier/Comparator/FET InputAmplifiers
- Datasheet: Texas Instruments LF156H/NOPB
- Number of Circuits: 1
- Operating Temperature: -55°C~+125°C
- Current - Input Bias(Ib): 30pA
- Gain Bandwidth Product(GBP): 5MHz
- Voltage - Input Offset(Vos): 3mV
- Package: TO-99-8
- Manufacturer: Texas Instruments
- Slew Rate: 12V/µs
- Voltage - Input Offset: 3mV
- Part Status: Active
- Packaging: Bulk
- Supplier Device Package: TO-99-8
- Package / Case: TO-99-8 Metal Can
- Voltage - Supply, Single/Dual (±): 10V ~ 44V, ±5V ~ 22V
- Series: BI-FET™
- Output Type: -
- Base Part Number: LF156
- Current - Supply: 5mA
- Mounting Type: Through Hole
- Amplifier Type: J-FET
- Current - Input Bias: 30pA
- Gain Bandwidth Product: 5MHz
- detail: J-FET Amplifier 1 Circuit TO-99-8
