TLV75201PDSQR دیتاشیت

TLV75201PDSQR

مشخصات دیتاشیت

نام دیتاشیت TLV75201PDSQR
حجم فایل 70.614 کیلوبایت
نوع فایل pdf
تعداد صفحات 31

دانلود دیتاشیت TLV75201PDSQR

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments TLV75201PDSQR
  • Package: DFN-10(2x2)
  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): 6V
  • Current - Quiescent (Iq): 35µA
  • Output Configuration: Positive
  • Base Part Number: TLV752
  • Voltage - Output (Min/Fixed): 0.55V
  • Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
  • Series: -
  • PSRR: 50dB ~ 30dB (1kHz ~ 1MHz)
  • Supplier Device Package: 10-WSON (2x2)
  • Package / Case: 10-WFDFN Exposed Pad
  • Number of Regulators: 2
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Part Status: Active
  • Output Type: Adjustable
  • Control Features: Enable
  • Voltage - Output (Max): 5.5V
  • Mounting Type: Surface Mount
  • Voltage Dropout (Max): 1.05V @ 1A
  • Current - Output: 1A
  • detail: Linear Voltage Regulator IC 2 Output 1A 10-WSON (2x2)
