دیتاشیت SN74AHC1GU04DCK3
مشخصات دیتاشیت
| نام دیتاشیت | SN74AHC1GU04 Datasheet |
|---|---|
| حجم فایل | 1195.66 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت SN74AHC1GU04 Datasheet |
SN74AHC1GU04 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Series: 74AHC
- Category: Logic ICs/Inverters
- Datasheet: Texas Instruments SN74AHC1GU04DCK3
- Sink Current: 8mA
- Source Current: 8mA
- Number of Inputs: 1
- Number of Circuits: 1
- Supply Current (Max): 1uA
- Low level range (VIL): 0.3V~1.1V
- Max Propagation Delay: 7ns@5V,50pF
- Operating Temperature: -40°C~+125°C
- High level range (VIH): 1.7V~4.4V
- Supply Voltage(Single): 2V~5.5V
- Package: SC-70-5
- Manufacturer: Texas Instruments
- Mounting Type: Surface Mount
- Logic Level - Low: 0.3V ~ 1.1V
- Current - Quiescent (Max): 1µA
- Voltage - Supply: 2V ~ 5.5V
- Packaging: Tube
- Package / Case: 5-TSSOP, SC-70-5, SOT-353
- Logic Level - High: 1.7V ~ 4.4V
- Part Status: Active
- Current - Output High, Low: 8mA, 8mA
- Features: -
- Base Part Number: SN74AHC1
- Supplier Device Package: SC-70-5
- Logic Type: Inverter
- Max Propagation Delay @ V, Max CL: 7ns @ 5V, 50pF
- detail: Inverter IC 1 Channel SC-70-5
