LM317L Datasheet دیتاشیت

LM317L Datasheet

مشخصات دیتاشیت

نام دیتاشیت LM317L Datasheet
حجم فایل 1753.029 کیلوبایت
نوع فایل pdf
تعداد صفحات 33

دانلود دیتاشیت LM317L Datasheet

دانلود دیتاشیت

سایر مستندات

TO-92 Packing Options 6 pages

LM317LITP/NOPB 43 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LM317LZ/LFT3
  • Output Type: Adjustable
  • Output Current: 100mA
  • Output Voltage: 1.2V~37V
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 40V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 5mA
  • Package: TO-92-3
  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): 40V
  • Output Configuration: Positive
  • Base Part Number: LM317
  • Voltage - Output (Min/Fixed): 1.2V
  • Protection Features: Over Current, Over Temperature, Short Circuit
  • Series: -
  • PSRR: 80dB ~ 65dB (120Hz)
  • Supplier Device Package: TO-92-3
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
  • Number of Regulators: 1
  • Part Status: Active
  • Control Features: -
  • Voltage - Output (Max): 37V
  • Mounting Type: Through Hole
  • Voltage Dropout (Max): -
  • Current - Output: 100mA
  • detail: Linear Voltage Regulator IC 1 Output 100mA TO-92-3
