دیتاشیت LP2950ACZ-5.0/LFT1

LP2950-N, 51-N Datasheet

مشخصات دیتاشیت

نام دیتاشیت LP2950-N, 51-N Datasheet
حجم فایل 2490.33 کیلوبایت
نوع فایل pdf
تعداد صفحات 57

دانلود دیتاشیت LP2950-N, 51-N Datasheet

LP2950-N, 51-N Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LP2950ACZ-5.0/LFT1
  • Output Current: 100mA
  • Output Voltage: 5V
  • Dropout Voltage: 0.6V@(100mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 35V
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Quiescent Current (Ground Current): 120uA
  • Package: TO-92-3
  • Manufacturer: Texas Instruments
  • Current - Supply (Max): 14mA
  • Voltage - Input (Max): 30V
  • Current - Quiescent (Iq): 120µA
  • Output Configuration: Positive
  • Base Part Number: LP2950
  • Voltage - Output (Min/Fixed): 5V
  • Protection Features: Over Current, Over Temperature, Short Circuit
  • Series: -
  • PSRR: -
  • Supplier Device Package: TO-92-3
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA)
  • Number of Regulators: 1
  • Part Status: Active
  • Output Type: Fixed
  • Control Features: -
  • Voltage - Output (Max): -
  • Mounting Type: Through Hole
  • Voltage Dropout (Max): 0.6V @ 100mA
  • Current - Output: 100mA
  • detail: Linear Voltage Regulator IC 1 Output 100mA TO-92-3
