CD74AC534M96 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | CD74AC534M96 |
|---|---|
| حجم فایل | 86.728 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 18 |
دانلود دیتاشیت CD74AC534M96 |
دانلود دیتاشیت |
|---|
سایر مستندات
CD54,74AC(T)374,534 17 pages
مشخصات فنی
- RoHS: true
- Type: D-Type
- Series: 74AC
- Category: Logic ICs/Flip Flops
- Function: Standard
- Datasheet: Texas Instruments CD74AC534M96
- Output Type: Tri-State;Inverted
- Sink Current: 24mA
- Trigger Type: 上升沿
- Source Current: 24mA
- Supply Voltage: 1.5V~5.5V
- Clock Frequency: 125MHz
- Input Capacitance: 10pF
- Quiescent Current (Iq): 8uA
- Maximum Propagation Delay: 11.3ns@5V,50pF
- Package: SOP-20-300mil
- Manufacturer: Texas Instruments
- Number of Elements: 1
- Voltage - Supply: 1.5V ~ 5.5V
- Operating Temperature: -55°C ~ 125°C (TA)
- Package / Case: 20-SOIC (0.295", 7.50mm Width)
- Packaging: Cut Tape (CT)
- Supplier Device Package: 20-SOIC
- Number of Bits per Element: 8
- Current - Output High, Low: 24mA, 24mA
- Part Status: Active
- Base Part Number: 74AC534
- Mounting Type: Surface Mount
- Current - Quiescent (Iq): 8µA
- Max Propagation Delay @ V, Max CL: 11.3ns @ 5V, 50pF
- detail: Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-SOIC (0.295", 7.50mm Width)
