TMUX1104 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TMUX1104
|
|
حجم فایل
|
1904.214
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
38
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TMUX1104DQAR
-
Package:
DFN-10(1x2.5)
-
Manufacturer:
Texas Instruments
-
Switch Time (Ton, Toff) (Max):
12ns, 5ns (Typ)
-
Channel-to-Channel Matching (ΔRon):
130mOhm
-
Voltage - Supply, Single (V+):
1.08V ~ 5.5V
-
Part Status:
Active
-
Voltage - Supply, Dual (V±):
-
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Number of Circuits:
1
-
Packaging:
Cut Tape (CT)
-
Crosstalk:
-45dB @ 10MHz
-
Current - Leakage (IS(off)) (Max):
80pA
-
Package / Case:
10-UFDFN
-
-3db Bandwidth:
155MHz
-
Series:
-
-
Channel Capacitance (CS(off), CD(off)):
6pF, 28pF
-
On-State Resistance (Max):
4Ohm
-
Supplier Device Package:
10-USON (2.5x1)
-
Base Part Number:
TMUX11
-
Multiplexer/Demultiplexer Circuit:
4:1
-
Switch Circuit:
SP4T
-
Charge Injection:
1.5pC
-
detail:
1 Circuit IC Switch 4:1 4Ohm 10-USON (2.5x1)
