TMUX1111RSVR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TMUX1111RSVR	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TMUX1111RSVR
Supply Voltage: 1.08V~5.5V
Switch Circuit: SPST(SPST)
Number of Channels: 4
On-State Resistance (Max): 4Ω
Package: UQFN-16
Manufacturer: Texas Instruments
Switch Time (Ton, Toff) (Max): -
Channel-to-Channel Matching (ΔRon): 130mOhm
Voltage - Supply, Single (V+): 1.08V ~ 5.5V
Part Status: Active
Voltage - Supply, Dual (V±): -
Operating Temperature: -40°C ~ 125°C (TA)
Number of Circuits: 4
Packaging: Cut Tape (CT)
Crosstalk: -90dB @ 10MHz
Current - Leakage (IS(off)) (Max): 80pA
Package / Case: 16-UFQFN
-3db Bandwidth: 300MHz
Series: -
Channel Capacitance (CS(off), CD(off)): 7pF, 10pF
Supplier Device Package: 16-UQFN (2.6x1.8)
Base Part Number: TMUX11
Multiplexer/Demultiplexer Circuit: 1:1
Charge Injection: -1.5pC
detail: 4 Circuit IC Switch 1:1 4Ohm 16-UQFN (2.6x1.8)
