LM2991T/LB03 Datasheet

LM2991

Datasheet specifications

Datasheet's name LM2991
File size 2354.211 KB
File type pdf
Number of pages 27

Download Datasheet LM2991

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Voltage - Input (Max): -26V
  • Packaging: Tube
  • Series: -
  • Current - Quiescent (Iq): 0.7mA
  • Current - Supply (Max): 5mA
  • Voltage - Output (Min/Fixed): -3V
  • Number of Regulators: 1
  • PSRR: 60dB (1kHz)
  • Supplier Device Package: TO-220-5
  • Package / Case: TO-220-5
  • Control Features: Enable
  • Part Status: Not For New Designs
  • Base Part Number: LM2991
  • Voltage Dropout (Max): 1V @ 1A
  • Operating Temperature: -40°C ~ 125°C
  • Current - Output: 1A
  • Output Configuration: Negative
  • Manufacturer: Texas Instruments
  • Mounting Type: Through Hole
  • Voltage - Output (Max): -24V
  • Output Type: Adjustable
  • Protection Features: Over Temperature, Short Circuit
  • detail: Linear Voltage Regulator IC 1 Output 1A TO-220-5
