- دیتاشیت MSP430FR6989IPZ
MSP430FR6989IPZ دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MSP430FR6989IPZ |
|---|---|
| حجم فایل | 90.116 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 187 |
دانلود دیتاشیت MSP430FR6989IPZ |
دانلود دیتاشیت |
|---|
سایر مستندات
MSP430FR58,59,68,69xx User Guide 1024 pages
MSP430FR598x(1), 698x(1) Datasheet 184 pages
مشخصات فنی
- RoHS: true
- CPU Core: MSP430
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 12bit
- Datasheet: Texas Instruments MSP430FR5988IRGCT
- CPU Maximum Speed: 16MHz
- GPIO Ports Number: 48
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Direct Memory Access: Yes
- Program Storage Size: 96KB
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Package: VQFN-64(9x9)
- Manufacturer: Texas Instruments
- Speed: 16MHz
- Data Converters: A/D 12x12b
- Oscillator Type: Internal
- Package / Case: 64-VFQFN Exposed Pad
- Packaging: Cut Tape (CT)
- Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, WDT
- Part Status: Active
- Supplier Device Package: 64-VQFN (9x9)
- RAM Size: 2K x 8
- Program Memory Type: FRAM
- Core Size: 16-Bit
- Core Processor: CPUXV2
- Program Memory Size: 96KB (96K x 8)
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Number of I/O: 48
- Base Part Number: 430FR5988
- Series: MSP430™ FRAM
- EEPROM Size: -
- Connectivity: I²C, IrDA, SPI, UART/USART
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- detail: CPUXV2 MSP430™ FRAM Microcontroller IC 16-Bit 16MHz 96KB (96K x 8) FRAM 64-VQFN (9x9)
