REG104 Datasheet Datasheet

REG104 Datasheet

Datasheet specifications

Datasheet's name REG104 Datasheet
File size 1092.1 KB
File type pdf
Number of pages 22

Download Datasheet REG104 Datasheet

Download Datasheet

Other documentations

REG104GA-3.3/2K5 23 pages

Technical specifications

  • RoHS: true
  • Feature: Overcurrent Protection;Thermal Protection
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments REG104GA-AG4
  • Output Type: Adjustable
  • Output Current: 1A
  • Output Voltage: 1.295V~5.5V
  • Dropout Voltage: 0.48V@(1A)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 15V
  • Operating Temperature: -40°C~+85°C
  • Quiescent Current (Ground Current): 0.7mA
  • Power Supply Rejection Ratio (PSRR): 65dB@(120Hz)
  • Package: SOT-223-6
  • Manufacturer: Texas Instruments
  • Current - Supply (Max): 1.8mA
  • Output Configuration: Positive
  • Package / Case: SOT-223-6
  • Packaging: Tube
  • Protection Features: Over Current, Over Temperature
  • Number of Regulators: 1
  • Part Status: Active
  • Current - Quiescent (Iq): 0.7mA
  • Supplier Device Package: SOT-223-6
  • Voltage - Input (Max): 15V
  • Voltage - Output (Min/Fixed): 1.295V
  • Mounting Type: Surface Mount
  • PSRR: 65dB (120Hz)
  • Base Part Number: REG104
  • Series: -
  • Control Features: Enable
  • Voltage - Output (Max): 5.5V
  • Voltage Dropout (Max): 0.48V @ 1A
  • Current - Output: 1A
  • detail: Linear Voltage Regulator IC 1 Output 1A SOT-223-6
