XF28M35x دیتاشیت

XF28M35x

مشخصات دیتاشیت

نام دیتاشیت XF28M35x
حجم فایل 2537.126 کیلوبایت
نوع فایل pdf
تعداد صفحات 240

دانلود دیتاشیت XF28M35x

دانلود دیتاشیت

سایر مستندات

F28M35H52C1RFPT 230 pages

F28M35x Tech Ref Manual 1655 pages

F28N35x Errata 55 pages

TI-RTOS 2.00 User Guide 133 pages

مشخصات فنی

  • CAN: -
  • I2C: -
  • I2S: -
  • SPI: -
  • RoHS: true
  • EEPROM: -
  • CPU Core: ARMOther series
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 136KB
  • Watchdog: Yes
  • ADC (Bit): 12bit
  • DAC (Bit): -
  • Datasheet: Texas Instruments F28M35H52C1RFPQ
  • PWM (Bit): -
  • 8Bit Timer: -
  • LCD Module: -
  • LED Module: -
  • UART/USART: -
  • 16Bit Timer: -
  • 32Bit Timer: -
  • Real-Time Clock: -
  • Application Area: -
  • CPU Maximum Speed: 100MHz;150MHz
  • GPIO Ports Number: 74
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: PWM
  • Program Memory Type: FLASH
  • Direct Memory Access: Yes
  • Program Storage Size: 512KB
  • Universal Serial Bus: Yes
  • communication protocol: -
  • Operating Voltage Range: -
  • Infrared Data Association: -
  • Operating Temperature Range: -40°C~+125°C
  • Secure Digital Input and Output: -
  • Package: HTQFP-144(20x20)
  • Manufacturer: Texas Instruments
  • Speed: 100MHz/150MHz
  • Data Converters: A/D 20x12b
  • Oscillator Type: -
  • Package / Case: 144-TQFP Exposed Pad
  • Packaging: Tray
  • Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, WDT
  • Part Status: Active
  • Supplier Device Package: 144-HTQFP (20x20)
  • Core Size: 32-Bit Dual-Core
  • Core Processor: C28x/ARM® Cortex®-M3
  • Program Memory Size: 512KB/512KB
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Number of I/O: 74
  • Base Part Number: F28M35
  • Series: C2000™ C28x + ARM® Cortex® M3 Concerto™
  • EEPROM Size: -
  • Connectivity: CANbus, EBI/EMI, Ethernet, I²C, SCI, SPI, SSI, UART/USART, USB, USB OTG
  • Voltage - Supply (Vcc/Vdd): 1.2V, 1.8V, 3.3V
  • detail: C28x/ARM® Cortex®-M3 C2000™ C28x + ARM® Cortex® M3 Concerto™ Microcontroller IC 32-Bit Dual-Core 100MHz/150MHz 512KB/512KB FLASH 144-HTQFP (20x20)
