دیتاشیت TLV74310PDBVR
مشخصات دیتاشیت
| نام دیتاشیت | TLV74310PDBVR |
|---|---|
| حجم فایل | 73.199 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 39 |
TLV74310PDBVR |
دانلود دیتاشیت |
|---|
سایر مستندات
TLV743xx Datasheet 38 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TLV74310PDBVR
- Output Current: 300mA
- Output Voltage: 1V
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 5.5V
- Operating Temperature: -40°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 60uA
- Package: SOT-23-5
- Manufacturer: Texas Instruments
- Base Part Number: TLV743
- Supplier Device Package: SOT-23-5
- Voltage - Output (Max): -
- Output Configuration: Positive
- Current - Quiescent (Iq): 60µA
- Output Type: Fixed
- PSRR: 68dB ~ 28dB (100Hz ~ 100kHz)
- Voltage Dropout (Max): -
- Number of Regulators: 1
- Mounting Type: Surface Mount
- Packaging: Cut Tape (CT)
- Voltage - Output (Min/Fixed): 1V
- Protection Features: Current Limit, Thermal Shutdown, UVLO
- Series: -
- Voltage - Input (Max): 5.5V
- Current - Output: 300mA
- Part Status: Active
- Package / Case: SC-74A, SOT-753
- Control Features: Enable
- detail: Linear Voltage Regulator IC 1 Output 300mA SOT-23-5
