L6984TR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت L6984TR	دانلود دیتاشیت

L6984 47 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: STMicroelectronics L6984TR
Input Voltage: 4.5V~36V
Output Voltage: 0.9V~28V
Number of Outputs: 1
Switching Frequency: 600kHz
Output Current (Max): 400mA
Operating Temperature: -40°C~+150°C@(TJ)
Synchronous Rectification: Yes
Package: VFDFPN-10
Manufacturer: STMicroelectronics
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Output Type: Adjustable (Fixed)
Voltage - Input (Min): 4.5V
Voltage - Input (Max): 36V
Voltage - Output (Min/Fixed): 0.9V (3.3V)
Voltage - Output (Max): 28V
Current - Output: 400mA
Frequency - Switching: 250kHz ~ 600kHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 10-VDFN Exposed Pad
Supplier Device Package: 10-VFDFPN (4x4)
Base Part Number: L6984
detail: Buck Switching Regulator IC Positive Adjustable (Fixed) 0.9V (3.3V) 1 Output 400mA 10-VDFN Exposed Pad
