TPD1E0B04DPLR دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TPD1E0B04DPLR	دانلود دیتاشیت

RoHS: true
Category: TVS/Fuse/Board Level Protection/TVS
Datasheet: Texas Instruments TPD1E0B04DPLR
Breakdown Voltage: 6.7V@Typ
Bidirectional Channels: 1
Maximum Clamping Voltage: 10.1V
Reverse Stand-Off Voltage (Vrwm): 3.6V@Max
Peak Pulse Current (Ipp)@10/1000us: 1.7A@8/20?A
Peak Pulse Power Dissipation (Ppp)@10/1000us: 15W
Package: X2-SON-2
Manufacturer: Texas Instruments
Type: Zener
Supplier Device Package: 2-X2SON (0.6x0.3)
Current - Peak Pulse (10/1000µs): 1.7A (8/20µA)
Applications: RF Antenna
Voltage - Reverse Standoff (Typ): 3.6V (Max)
Voltage - Breakdown (Min): 6.7V (Typ)
Voltage - Clamping (Max) @ Ipp: 10.1V
Capacitance @ Frequency: 0.13pF @ 1MHz
Mounting Type: Surface Mount
Power Line Protection: No
Base Part Number: TPD1E
Packaging: Digi-Reel®
Operating Temperature: -40°C ~ 125°C (TA)
Series: -
Power - Peak Pulse: 15W
Package / Case: 0201 (0603 Metric)
Part Status: Active
detail: 10.1V Clamp 1.7A (8/20µA) Ipp Tvs Diode Surface Mount 2-X2SON (0.6x0.3)
