دیتاشیت TLV75510PDBVR
مشخصات دیتاشیت
| نام دیتاشیت |
TLV755P
|
| حجم فایل |
2774.905
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
43
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TLV75510PDBVR
-
Output Current:
500mA
-
Output Voltage:
1V
-
Dropout Voltage:
0.825V@(500mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+125°C@(Tj)
-
Quiescent Current (Ground Current):
31uA
-
Package:
SOT-23-5
-
Manufacturer:
Texas Instruments
-
Base Part Number:
TLV755
-
Supplier Device Package:
SOT-23-5
-
Voltage - Output (Max):
-
-
Output Configuration:
Positive
-
Current - Quiescent (Iq):
31µA
-
Output Type:
Fixed
-
PSRR:
52dB (1kHz ~ 1MHz)
-
Voltage Dropout (Max):
0.825V @ 500mA
-
Number of Regulators:
1
-
Mounting Type:
Surface Mount
-
Packaging:
Cut Tape (CT)
-
Voltage - Output (Min/Fixed):
1V
-
Protection Features:
Over Current, Over Temperature
-
Series:
-
-
Voltage - Input (Max):
5.5V
-
Current - Output:
500mA
-
Part Status:
Active
-
Package / Case:
SC-74A, SOT-753
-
Control Features:
Enable
-
detail:
Linear Voltage Regulator IC 1 Output 500mA SOT-23-5
