STTH3002CR دیتاشیت

STTH3002CR

مشخصات دیتاشیت

نام دیتاشیت STTH3002CR
حجم فایل 141.675 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

مشاهده دیتاشیت STTH3002CR

دانلود دیتاشیت

سایر مستندات

STTH3002C Datasheet 11 pages

Diodes & Rectifiers Selection Guide 28 pages

W Series for Welding Applications 2 pages

مشخصات فنی

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Diode Configuration: 1 Pair Common Cathode
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 200V
  • Current - Average Rectified (Io) (per Diode): 15A
  • Voltage - Forward (Vf) (Max) @ If: 1.05V @ 15A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 22ns
  • Current - Reverse Leakage @ Vr: 20µA @ 200V
  • Operating Temperature - Junction: 175°C (Max)
  • Mounting Type: Through Hole
  • Package / Case: TO-262-3 Long Leads, I²Pak, TO-262AA
  • Supplier Device Package: I2PAK
  • Base Part Number: STTH30
  • detail: Diode Array 1 Pair Common Cathode Standard 200V 15A Through Hole TO-262-3 Long Leads, I²Pak, TO-262AA
