SN74LVC1G86DBVRG4 دیتاشیت

SN74LVC1G86DBVRG4

مشخصات دیتاشیت

نام دیتاشیت SN74LVC1G86DBVRG4
حجم فایل 73.235 کیلوبایت
نوع فایل pdf
تعداد صفحات 29

دانلود دیتاشیت SN74LVC1G86DBVRG4

دانلود دیتاشیت

سایر مستندات

SN74LVC1G86 29 pages

مشخصات فنی

  • RoHS: true
  • Series: 74LVC
  • Category: Logic ICs/Gates
  • Datasheet: Texas Instruments SN74LVC1G86DBVRG4
  • Sink Current: 32mA
  • Source Current: 32mA
  • Supply Voltage: 1.65V~5.5V
  • Logic Gate Type: XORGate
  • Number of Channels: 1
  • Low Level Range (VIL): 0.7V~0.8V
  • Operating Temperature: -40°C~+125°C
  • High Level Range (VIH): 1.7V~2V
  • Propagation Delay Time: 4ns@5V,50pF
  • Quiescent Current (Max): 10uA
  • Package: SOT-23-5
  • Manufacturer: Texas Instruments
  • Logic Level - High: 1.7V ~ 2V
  • Base Part Number: SN74LVC1G
  • Supplier Device Package: SOT-23-5
  • Logic Level - Low: 0.7V ~ 0.8V
  • Package / Case: SC-74A, SOT-753
  • Current - Quiescent (Max): 10µA
  • Current - Output High, Low: 32mA, 32mA
  • Features: -
  • Mounting Type: Surface Mount
  • Packaging: Digi-Reel®
  • Voltage - Supply: 1.65V ~ 5.5V
  • Number of Circuits: 1
  • Max Propagation Delay @ V, Max CL: 4ns @ 5V, 50pF
  • Number of Inputs: 2
  • Part Status: Active
  • Logic Type: XOR (Exclusive OR)
  • detail: XOR (Exclusive OR) IC 1 Channel SOT-23-5
