SN74LV1T32DBVR دیتاشیت

SN74LV1T32DBVR

مشخصات دیتاشیت

نام دیتاشیت SN74LV1T32DBVR
حجم فایل 75.266 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

مشاهده دیتاشیت SN74LV1T32DBVR

دانلود دیتاشیت

سایر مستندات

SN74LV1T32 19 pages

مشخصات فنی

  • RoHS: true
  • Series: 74LV
  • Category: Logic ICs/Gates
  • Datasheet: Texas Instruments SN74LV1T32DBVR
  • Sink Current: 8mA
  • Source Current: 8mA
  • Supply Voltage: 1.6V~5.5V
  • Logic Gate Type: ORGate
  • Number of Channels: 1
  • Low Level Range (VIL): 0.58V~0.8V
  • Operating Temperature: -40°C~+125°C
  • High Level Range (VIH): 0.94V~2.1V
  • Propagation Delay Time: 7ns@5V,30pF
  • Quiescent Current (Max): 10uA
  • Package: SOT-23-5
  • Manufacturer: Texas Instruments
  • Logic Level - High: 0.94V ~ 2.1V
  • Base Part Number: SN74LV1T
  • Supplier Device Package: SOT-23-5
  • Logic Level - Low: 0.58V ~ 0.8V
  • Package / Case: SC-74A, SOT-753
  • Current - Quiescent (Max): 10µA
  • Current - Output High, Low: 8mA, 8mA
  • Features: -
  • Mounting Type: Surface Mount
  • Packaging: Cut Tape (CT)
  • Voltage - Supply: 1.6V ~ 5.5V
  • Number of Circuits: 1
  • Max Propagation Delay @ V, Max CL: 7ns @ 5V, 30pF
  • Number of Inputs: 2
  • Part Status: Active
  • Logic Type: OR Gate
  • detail: OR Gate IC 1 Channel SOT-23-5
