دیتاشیت LM2904LVIDDFR

LM290(2,4)LV

مشخصات دیتاشیت

نام دیتاشیت LM290(2,4)LV
حجم فایل 2477.446 کیلوبایت
نوع فایل pdf
تعداد صفحات 41

دانلود دیتاشیت LM290(2,4)LV

LM290(2,4)LV Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments LM2904LVIDDFR
  • -3db Bandwidth: -
  • Output Current: 40mA
  • Operating Temperature: -40°C~+125°C
  • Current - Input Bias(Ib): 15pA
  • Gain Bandwidth Product(GBP): 1MHz
  • Package: SOT-23-8
  • Manufacturer: Texas Instruments
  • Current - Output / Channel: 40mA
  • Current - Supply: 90µA
  • Voltage - Input Offset: 1mV
  • Supplier Device Package: SOT-23-8
  • Slew Rate: 1.5V/µs
  • Amplifier Type: General Purpose
  • Mounting Type: Surface Mount
  • Output Type: -
  • Current - Input Bias: 15pA
  • Gain Bandwidth Product: 1MHz
  • Base Part Number: LM290
  • Packaging: Cut Tape (CT)
  • Number of Circuits: 2
  • Series: -
  • Package / Case: SOT-23-8
  • Part Status: Active
  • Voltage - Supply, Single/Dual (±): 2.7V ~ 5.5V, ±1.35V ~ 2.75V
  • detail: General Purpose Amplifier 2 Circuit SOT-23-8
