TPS7A0512PYKAR دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TPS7A0512PYKAR	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TPS7A0512PYKAR
Output Current: 200mA
Output Voltage: 1.2V
Dropout Voltage: 0.679V@(200mA)
Output Polarity: positive
Number of Outputs: 1
Maximum Input Voltage: 5.5V
Operating Temperature: -40°C~+125°C@(Tj)
Quiescent Current (Ground Current): 3uA
Package: BGA-4
Manufacturer: Texas Instruments
Base Part Number: TPS7A0
Supplier Device Package: 4-DSBGA
Voltage - Output (Max): -
Output Configuration: Positive
Current - Quiescent (Iq): 3µA
Output Type: Fixed
PSRR: 40dB (1kHz ~ 1MHz)
Voltage Dropout (Max): 0.679V @ 200mA
Number of Regulators: 1
Mounting Type: Surface Mount
Packaging: Cut Tape (CT)
Voltage - Output (Min/Fixed): 1.2V
Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Series: -
Voltage - Input (Max): 5.5V
Current - Output: 200mA
Part Status: Active
Package / Case: 4-XFBGA, DSBGA
Control Features: Enable
detail: Linear Voltage Regulator IC 1 Output 200mA 4-DSBGA
