دیتاشیت TL431LIAEDBZRQ1
مشخصات دیتاشیت
| نام دیتاشیت | TL431LI-Q1, TL432LI-Q1 |
|---|---|
| حجم فایل | 1547.36 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت TL431LI-Q1, TL432LI-Q1 |
TL431LI-Q1, TL432LI-Q1 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: Texas Instruments TL431LIAEDBZRQ1
- Tolerance: ±1%
- Output Type: Adjustable
- Output Current: 15mA
- Output Voltage: 2.495V~36V
- Reference Type: parallel connection
- Operating Temperature: -40°C~+150°C@(Ta)
- Package: SOT-23-3
- Manufacturer: Texas Instruments
- Temperature Coefficient: -
- Base Part Number: TL431
- Current - Cathode: 600µA
- Voltage - Output (Max): 36V
- Part Status: Active
- Supplier Device Package: SOT-23-3
- Mounting Type: Surface Mount
- Current - Supply: -
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Voltage - Output (Min/Fixed): 2.495V
- Series: Automotive, AEC-Q100
- Voltage - Input: -
- Current - Output: 15mA
- Noise - 0.1Hz to 10Hz: -
- Noise - 10Hz to 10kHz: -
- detail: Shunt Voltage Reference IC 36V ±1% SOT-23-3
