دیتاشیت LM358LVIDDFR

LM321LV, LM324LV, LM358LV

مشخصات دیتاشیت

نام دیتاشیت LM321LV, LM324LV, LM358LV
حجم فایل 2801.71 کیلوبایت
نوع فایل pdf
تعداد صفحات 47

دانلود دیتاشیت LM321LV, LM324LV, LM358LV

LM321LV, LM324LV, LM358LV Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments LM358LVIDDFR
  • -3db Bandwidth: -
  • Output Current: 40mA
  • Operating Temperature: -40°C~+125°C
  • Current - Input Bias(Ib): 15pA
  • Gain Bandwidth Product(GBP): 1MHz
  • Package: SOT-23-8
  • Manufacturer: Texas Instruments
  • Current - Output / Channel: 40mA
  • Current - Supply: 90µA
  • Voltage - Input Offset: 1mV
  • Supplier Device Package: SOT-23-8
  • Slew Rate: 1.5V/µs
  • Amplifier Type: General Purpose
  • Mounting Type: Surface Mount
  • Output Type: -
  • Current - Input Bias: 15pA
  • Gain Bandwidth Product: 1MHz
  • Base Part Number: LM358
  • Packaging: Cut Tape (CT)
  • Number of Circuits: 2
  • Series: -
  • Package / Case: SOT-23-8
  • Part Status: Active
  • Voltage - Supply, Single/Dual (±): 2.7V ~ 5.5V, ±1.35V ~ 2.75V
  • detail: General Purpose Amplifier 2 Circuit SOT-23-8
