SN74AUC2G53DCTR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SN74AUC2G53DCTR
|
|
حجم فایل
|
55.083
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
26
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments SN74AUC2G53DCTR
-
Turn-on time:
2.2ns
-
Turn-off time:
2.3ns
-
Supply Voltage:
0.8V~2.7V
-
Switch Circuit:
SPDT(SPDT)
-
Number of Channels:
1
-
On-State Resistance (Max):
15Ω
-
Package:
SSOP-8
-
Manufacturer:
Texas Instruments
-
Voltage - Supply, Single (V+):
0.8V ~ 2.7V
-
Multiplexer/Demultiplexer Circuit:
2:1
-
Current - Leakage (IS(off)) (Max):
1µA
-
Crosstalk:
-60dB @ 1MHz
-
Voltage - Supply, Dual (V±):
-
-
Packaging:
Cut Tape (CT)
-
Channel-to-Channel Matching (ΔRon):
1Ohm (Max)
-
Charge Injection:
-
-
Supplier Device Package:
SM8 (SSOP)
-
-3db Bandwidth:
50MHz
-
Base Part Number:
SN74AUC2
-
Mounting Type:
Surface Mount
-
Channel Capacitance (CS(off), CD(off)):
2pF
-
Switch Time (Ton, Toff) (Max):
2.2ns, 2.3ns
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Number of Circuits:
1
-
Series:
-
-
Package / Case:
8-LSSOP, 8-MSOP (0.110", 2.80mm Width)
-
Part Status:
Active
-
detail:
1 Circuit IC Switch 2:1 15Ohm SM8 (SSOP)
