SN74AUP3G14DCUR دیتاشیت

SN74AUP3G14DCUR

مشخصات دیتاشیت

نام دیتاشیت SN74AUP3G14DCUR
حجم فایل 96.445 کیلوبایت
نوع فایل pdf
تعداد صفحات 27

مشاهده دیتاشیت SN74AUP3G14DCUR

دانلود دیتاشیت

سایر مستندات

SN74AUP3G14 24 pages

مشخصات فنی

  • RoHS: true
  • Series: 74AUP
  • Category: Logic ICs/Inverters
  • Datasheet: Texas Instruments SN74AUP3G14DCUR
  • Input Type: Schmitt Trigger
  • Sink Current: 4mA
  • Source Current: 4mA
  • Number of Inputs: 3
  • Number of Circuits: 3
  • Supply Current (Max): 500nA
  • Low level range (VIL): 0.1V~0.88V
  • Max Propagation Delay: 6.2ns@3.3V,30pF
  • Operating Temperature: -40°C~+85°C
  • High level range (VIH): 0.6V~2.29V
  • Supply Voltage(Single): 0.8V~3.6V
  • Package: VSSOP-8
  • Manufacturer: Texas Instruments
  • Logic Level - High: 0.6V ~ 2.29V
  • Base Part Number: SN74AUP
  • Supplier Device Package: 8-VSSOP
  • Logic Level - Low: 0.1V ~ 0.88V
  • Package / Case: 8-VFSOP (0.091", 2.30mm Width)
  • Current - Quiescent (Max): 500nA
  • Current - Output High, Low: 4mA, 4mA
  • Features: Schmitt Trigger
  • Mounting Type: Surface Mount
  • Packaging: Cut Tape (CT)
  • Voltage - Supply: 0.8V ~ 3.6V
  • Max Propagation Delay @ V, Max CL: 6.2ns @ 3.3V, 30pF
  • Part Status: Active
  • Logic Type: Inverter
  • detail: Inverter IC 3 Channel Schmitt Trigger 8-VSSOP
